470G LC, All SN Ranges

Number: 7048
Catalog: Undercarriage
Manufacturer: John Deere
Family: Excavator
Model: 470G LC
Serial # Range: All

Track Group
Pic	Sku	Name	Qty per
	HT22753	53 LINK RAIL [+-] Description 53 LINK CHAIN USE BOLT AND NUT # 4328034 AND 4328035 ONLY ONLY ONLY!!!!!!!!!!!!! R.H LINK AT201777 L.H. LINK AT201778 PIN CR4727 BUSHING CR1539	2
	HT22753B	BERCO TRK. CHAINS 53 LK.	2
	4328034	TRACK BOLT M24x1.5x72F WASHER	424
	1783211220	TRACK SHOE NUT 24MM SQUARE FIN	424
	KM1426750	750MM TG SHOE	106
	KM1426800	800MM TG SHOE	106
	KM1426900	900MM TG SHOE	106
Rollers and Mounting Hardware
Pic	Sku	Name	Qty per
	LH90E	SF ROLLER	18
	0101162210	BOLT (22MM X 110MM)	72
	9099140	TOP ROLLER [+-] Description TOP ROLLER HIT EX400LC-3, 450LC-5 & J.D.	6
Sprocket Group
Pic	Sku	Name	Qty per
	FT3061	HITACHI EX-400 SPROCKET	2
	0101032270	BOLT	48
	3B4514	7/8" LOCK WASHER	48
Idler Group
Pic	Sku	Name	Qty per
	HT756	IDLER W/BRACKETS (9244297)	2
	6V3532	BOLT 20mm X 2.5 x 60mm	8
	12M7070	LOCK WASHER 20MM old# 0160202	8
