| Track Group |
| Pic |
Sku |
Name |
Qty per |
|
|
CR426138K |
38 LINK SALT RAIL
|
2 |
|
|
CR426138 |
38 LINK SALT RAIL
|
2 |
|
|
1M1408 |
NUT, TRACK 5/8"
|
296 |
|
|
7H3597 |
TRACK SHOE BOLT 5/8"
|
296 |
|
|
CR297418 |
18" SG SHOE
|
74 |
|
|
CR357118 |
18" SG MASTER SHOE
|
2 |
| Bill of Materials |
| Pic |
Sku |
Name |
Qty per |
| [+-] |
|
|
CR4333 |
R H LINK
|
1 |
|
|
CR4334 |
L H LINK
|
1 |
| Rollers and Mounting Hardware |
| Pic |
Sku |
Name |
Qty per |
|
|
ID789 |
S F ROLLER
|
6 |
|
|
ID1449 |
D.F. ROLLER
|
6 |
|
|
8S4734 |
BOLT-9/16" NC X 2"
|
48 |
|
|
3B4509 |
9/16" LOCK WASHER
|
48 |
|
|
CR2880 |
TOP ROLLER (CLAMP ON STYLE)
|
2 |
|
|
8T0207 |
BOLT (M16-2.00 X 100MM NC)
|
4 |
|
|
5P8247 |
5/8" FLAT WASHER
|
8 |
|
|
8T1757 |
16MM NUT (M16-2.00 NC)
[+-] Description
SEGMENT NUT (16MM USE W/1178509 BOLT ONLY MAKE SURE BOTH THEAD TOGETHER
|
4 |
| Sprocket Group - Segment |
| Pic |
Sku |
Name |
Qty per |
|
|
ID792 |
SPROCKET
|
2 |
|
|
1A8063 |
BOLT 3/4" X21/2" NC 1D4607
|
24 |
|
|
5P8248 |
3/4" FLAT WASHER
|
24 |
| Idler Group |
| Pic |
Sku |
Name |
Qty per |
|
|
ID3078 |
FRONT IDLER
|
2 |
|
|
8T0207 |
BOLT (M16-2.00 X 100MM NC)
|
4 |
|
|
5P8247 |
5/8" FLAT WASHER
|
8 |
| Track Adjust Seal Kit |
| Pic |
Sku |
Name |
Qty per |
|
|
905003 |
TRACK ADJUSTER SEAL KIT
[+-] Description
MUO: (450G, 455G, 550G, 555G, 650G)
|
2 |
|
|
